Product Details:
Payment & Shipping Terms:
|
Structure: | Vane Pump | Usage: | Hydraulic Vane Pump |
---|---|---|---|
Application: | Engineering Machinery, Rubber And Plastics Machinery Etc | Power: | Hydraulic |
Fuel: | Diesel | Pressure: | High Pressure |
Condition: | New | Sample Order: | Acceptable |
Single Pump: | 20V,25V,35V,45V,20VQ,25VQ,35VQ | Double Pump: | 2520V/VQ,3525V/VQ,3520V/VQ,4520V/VQ,4525V/VQ,4535V/VQ |
Warranty: | One Year Guarantee | Package: | Standard Export Package |
Max Speed: | 1800 R/min | Max Operation Pressure: | 20.7 Mpa |
Keywords: | Vickers V VQ Hydraulic Vane Pump For Factory Use | Theory: | Rotary Pump |
Standard Or Nonstandard: | Standard | Port: | Shanghai Port |
Characteritics
High Performance Intravane Pumps for plastic injection machinery, Shoe machinery, Tool machinery, Die casting machinery and Metallurge equipment.
1.Intravane pumps with hydraulic balancing structure provide more stable performance and longer life since less pressure from vane on stator.
2.Twelve vane system provide low amplitude flow pulsation resulting in low system noise characteristics.
3.Verious displacement and shafts with 4 different outlet opposite position make operation more flexible.
4.The cartridge is independent of the drive shaft, allowing for easy servicing without remore the pump from its mounting.
V series Pump:
20V, 25V, 35V, 45V, 2520V, 3520V, 3525V, 4520V, 4525V, 4535V
VQ Series pump:
20VQ, 25VQ, 35VQ, 45VQ, 2520VQ, 3520VQ, 3525VQ, 4520VQ, 4525VQ, 4535VQ
Usage :
Hydraulic vane pump are widely used in Heavy equipments, Mining machinery,Rubber & Plastic machinery, Shoes machinery, Die Casting Machinery, Metallurgical machinery, Metal Cutting Machinery and other types of hydraulic syste
Series |
Flow code (USgpm) |
Geometric displacement ml/r |
Max.operating pressure Mpa |
Max.speed r/min |
Min. Speed r/min |
20VQ | 2 | 7(0.43) | 21 | 2700 | 600 |
3 | 10(0.61) | ||||
4 | 13(0.79) | ||||
5 | 16.5(1.01) | ||||
6 | 19(1.16) | ||||
7 | 22(1.40) | ||||
8 | 27(1.67) | ||||
9 | 30(1.85) | ||||
10 | 31.5(1.92) | ||||
11 | 35(2.14) | ||||
12 | 40(2.44) | 16 | |||
14 | 45(2.78) | 14 | |||
25VQ | 10 | 32(1.95) | 21 | 2700 | 600 |
12 | 38(2.32) | ||||
14 | 43.5(2.65) | ||||
15 | 47(2.89) | 2500 | |||
17 | 54(3.30) | ||||
19 | 60(3.66) | ||||
21 | 67(4.13) | ||||
25 | 79.2(4.83) | ||||
35VQ | 21 | 67(4.13) | 21 | 2500 | 600 |
25 | 81(4.94) | ||||
30 | 95(5.80) | ||||
32 | 101(6.16) | ||||
35 | 109(6.65) | 2400 | |||
38 | 119(7.26) | ||||
45 | 143(8.72) | 14 | |||
45VQ | 42 | 134(8.17) | 17.5 | 2400 | 600 |
45 | 143(8.72) | 2200 | |||
50 | 159(9.70) | ||||
57 | 181(11.05) | ||||
60 | 189(11.53) | ||||
66 | 210(12.81) | ||||
75 | 237(14.46) | 14 |
